Density (Kg/m³) |
48 - 80 |
Kg/m³ |
ASTM D 1667 |
Thermal Conductivity (W/mk)
Mean Temp. (24°C) |
= 0.0356 W/mk |
W/mk |
ASTM C 177 |
|
Flammability |
Class V-0 |
- |
UL 94 |
|
Class A |
- |
ASTM E 84 |
|
Water Vapor Permeability (g/Pa.s.m) |
- |
g/Pa.s.m |
ASTM E 96 |
|
UV Weather Resistance |
Very Good |
|
ASTM G 154 |
|
Ozone Resistance |
No Crack |
- |
ASTM D 1149 |
|
Temp. Range |
-57° C to 125° C |
°C |
- |
|
Corrosion to Copper, Stainless Steel |
Non corrosive |
- |
DIN 1988 |
|
Nitrosamine Contents |
Not Present |
- |
U.S.FDA |
|
Closed Cell Foam |
Yes |
- |
- |
|
Standard Width/Length |
As Per Packing Standard |
- |
- |
|
Glass Cloth (GSM) |
200-220 |
|
- |
|
Glass Cloth TS (N/cm) |
Min 400 |
|
- |
|
Adhesive type |
Acrylic-PSA |
|
- |
